TOOL SHRINK Basic

TOOL SHRINK Basic is the leading developed entry-shrink technology for speed

Safety and flexibility for tool-holders.

Shrinking detail
TOOL SHRINK BASIC

FEATURES

  • Smart-coil solution (measures the resistance of the holder thickness) Low/optimized power consumption

  • Power consumption 7 - 15kw; no overheating

  • Fast shrinking and unclamping of ALL tool-holders from Ø 3 – 32mm

    • (40mm as well with the same coil)

    • HSS, Heavy metals / Carbide and MST; magnetic & or not tool-holders

  • Keypanel-Easy

  • EVO Pi-interface

    • (individual shrink cycles & for special/customized applications)

  • Air pressure connection from 3 to 6 bar

  • Max. shrinking length: 430 to 490mm

  • Long lifetime of the tool holders due to automatic shrinking cycles

  • High concentricity

  • Ergonomic design for enhanced safety during use

  • Shrink time approx. 2-7 seconds (depending on tool-holder shape)

  • Max. machine interface: HSK-A125

AVANTAGES

01.

Automatic adjusting kw & heating time for each holder

02.

Fast shrinking and unclamping of ALL tool-holders from Ø 3 – 32mm

03.

Reduced setup costs and downtime on tool replacement

04.

Long lifetime of the tool holders due to automatic shrinking cycles

05.

EVO Pi-interface +

Web-interface 4.0 with Online support

Tool Shrink Basic + air cooling box

TOOL SHRINK Basic  +  Air cooling box*  +  Easy Height*  +  Air power cooling*  (*options)

Air cooling box
Easy Height
Air power cooling
技术数据

POWER

20 Kw allowing shrink and unshrink of tool ∅ 3 to 32 mm

CAPABILITY

Tools shank ∅ 3 to 32 mm

MAX. SHRINKING LENGTH

430 to 490 mm

MAX. MACHINE INTERFACE

HSK-A125

DIMENSIONS

317 x 955 x 920 mm (W x D x H)

WEIGHT

45 kg

DELIVERY CONTENT

• Multi-function adapters for SK|BT|CAT 40 & 50; HSK 63|100; C6
• Smart coil with interchangeable stop discs
• Fans
• Protecting cone
• Pair of gloves
• Pi-Interface 4.0
• Online support interface

CONNECTIONS

Connections 3 Phase 400 - 480 V 16-25 A (EU/US)

EU​

  • AC 3 Phase 400 V (+/-10%) + PE/23.8 A/50-60 Hz

  • AC 3 Phase 400 V (+/-10%) + PE + N/23.8 A/50-60 Hz

US

  • AC 3 Phase 440 -480 V + GND /23.8 A/50-60 Hz

For other voltage supply a transformer is required (transformer ordered separately)
Input voltage: 3 x 208 / 240 / 480 / 600 VAC + GND/28 A/50-60 Hz
Output voltage: AC 3 x 400 V + PE + N/28 A/50-60 Hz

  • 3 meters cable is supplied

  • Air 3 to 6 bars / pipe ∅ 10 mm required

回到基础:热缩配合原理
热胀套的内径[1]设计为略小于刀柄直径[2]的切削工具。
放入电感时[3]循环开始后,由于局部高磁场,内孔被加热[4]generate.The inside ∅ will expands.然后可以轻松地将刀具柄滑入刀柄中。当刀柄冷却下来时,由此产生的热收缩会在刀柄的整个表面周围施加巨大而均匀的压力。
